Drill Casing

Description
Anchoring series casing is made of geological pipe material from Shanghai Baosteel Group. Its connection features convenient connection, good sealing effect and long lifespan. There are two types of this product. The integral type one has pin thread on one end and box thread on the other end. This type of casing pipe is connected directly without coupling transition. It is a little heavier. The other type has box thread on both ends. It has coupling transition and it is lightweight and easy to transport.

Features and Advantages
1. This casing pipe has superior properties. It is abrasion resistant.
2. This product has high strength. It can meet the depth requirement to the largest extent.
3. We have introduced advanced technology and equipment to ensure good product quality.
4. The casing has excellent cutting capacity in defined outside and inside free-cut area.
5. The maintenance and repair of casing pipe is very easy.

Parameters

Product Name	Product code	Unit	Length	Weight	Note
108 casing	MG108-10000-1	Piece	1 m	24 kg	Casing specification and thread number are opitonal
108 casing	MG108-20000-1	Piece	2 m	46.3 kg
127 casing	MG127-1500-3-0	Piece	1.5 m	42.4 kg
	MG127-2000-3-0	Piece	2 m	53.1 kg
	MG127-3000-3-0	Piece	3 m	75.1 kg
140 casing	MG140-1500-7-0	Piece	1.5 m	48.3 kg
	MG140-2000-7-0	Piece	2 m	60.9 kg
	MG140-3000-7-0	Piece	3 m	86 kg
146 casing	MG146-1500-1B-0	Piece	1.5 m	45.1 kg
	MG146-2000-1B-0	Piece	2 m	57.9 kg
	MG146-3000-1B-0	Piece	3 m	83.3 kg

Wuxi Anmai Construction Machinery Co., Ltd. is a specialized manufacturer and supplier of engineering machinery. Anmai provides clients with high quality casing pipes. We have cooperated with many universities and postgraduates, engaged in the research of basic engineering equipments. We have developed many drilling equipments dominating the trend of markets, such as MD series drilling machinery, XP series jet grouting anchor drilling machines, CWP series pump trucks and BP-1, etc.
