XP-30 Jet Grouting Drilling Rig

Advantages of Our Drilling Rig
1. Our drill rigs can be configured with a full set jet grouting equipment, and also can be customized according to the demands of customers. Additionally, we provide on-site operating training and demonstrate the pore-forming.
2. Our jet grouting drilling rig uses full hydraulic technique. What's more, we make breakthrough in key technologies, such as jet grouting lifting. We also add stepless speed regulation module when the anchoring is drilling, which makes the operation more convenient.

Description
This jet grouting drill rig is used for transporting the slurry, compressed air, water and other medium. It is a kind of drilling tools which should keep continuous dynamic and static tightness under the high-pressure working conditions.
This jet grouting drilling rig is available for the soft ground reinforcement, anti-seepage treatment of the high-rise building basement, repairing of river bank as well as pier reinforcement of railway and highway.

Composition of Drill Rig
This jet grouting drilling rig consists of power head, operating board, mast, oil tank, pump station, electrical cabinet and winch. The drilling tool is mainly composed of drill rod, diverter, drilling bit, locking device, forks and adjustable joints.

Features of Drill Rig
1. With good adaptability, this jet grouting drilling rig can be configured with different modules and drilling tools, so as to solve various jet grouting processes.
2. Our drill rig is suitable for broad stratums. This drilling equipment has various performance configurations according to different strata.
3. The pore-forming can choose carbide drill, DTH hammer and roller bit to conduct rotary drilling, so that this drill rig can be used for pore-creating in most strata, and can carry out jet grouting pile-forming immediately.
4. Besides jet grouting process, this jet grouting drilling rig is available for the construction of anchoring technology.
5. This drill rig can accomplish drilling hole and jet grouting process in once time when operating in some certain soft layer. During the jet grouting lifting, the depth of the rotary jet shall not exceed the height of the assistant tower (15m). There is no need to dismantle the drill rod.
6. The shifting and turning of the drill rig, speed change of power head and drill lifting are all adopted hydraulic control, featuring in flexible operation, saving time and labor cost.
7. Using special technology, this jet grouting drilling rig can shift without crosstie, which may greatly lessen labor intensity, reduce construction costs and improve operating efficiency.
8. The drill rigs adopt double winches and electrical control which can reduce labor force and enhance production efficiency.

Parameters of XP-30 Jet Grouting Drilling Rig

Anmai Construction Machinery Co., Ltd. is a professional drill rig manufacturer and supplier in China. We develop MD series anchor drilling rig, XP series jet grouting drilling rig, CWP series pump trucks, G series high-pressure jet grouting drilling tools and BP-1 series products. Our company has advanced and scientific production technology and capacity as well as rapid innovation ability, so that our drill rigs account for a large market share in the domestic market.
